The new MAX77659 single-inductor multiple-output (SIMO) power management IC (PMIC) with integrated switch-mode buck-boost charger from Analog Devices, Inc. charges wearables, hearables and Internet of Things (IoT) devices faster and in less space than any other PMIC available today. The MAX77659 SIMO PMIC delivers over four hours of playtime after a short, ten-minute charge, and uses a single inductor to power multiple rails, reducing the bill of materials (BOM) by 60 percent and shrinking total solution size by 50 percent.
- View the MAX77659 SIMO PMIC product page, download the datasheet and order samples: https://bit.ly/MAX77659Product
- Learn more about ADI’s low-power PMICs: https://bit.ly/MAX77659PMICs
- Download a high-resolution image: https://bit.ly/MAX77659Photo
- Connect with engineers and ADI product experts on EngineerZone, an online technical support community
The MAX77659 SIMO PMIC integrates a switch-mode buck-boost charger and three independently programmable buck-boost regulators, all sharing a single inductor to minimize total solution size. The regulators extend battery life by operating at 91 percent efficiency during moderate to heavy load conditions while consuming only 5µA of quiescent current during light load conditions. The MAX77659 SIMO PMIC supports autonomous headroom control, which reduces heat dissipation by minimizing the voltage drop while providing enough headroom to regulate the charging current.
“Analog Devices’ SIMO product technology shrinks size and boosts performance in the smallest of hearable and wearable devices,” said Roger Yeung, Executive Business Manager for the Battery Power Solutions Business Unit at Maxim Integrated, now part of Analog Devices. “The MAX77659 brings the ‘on-the-go’ lifestyle to the next level by minimizing plug-in time and maximizing play time. The MAX77659 PMIC frees up board real estate to pack in additional features such as expanded memory storage, location tracking and vital sensing demanded by today’s portable consumer and medical devices.”
MAX77659 SIMO PMIC Features and Benefits
- Fastest Charging: The MAX77659 integrates a switch mode buck-boost charger that charges wearables and hearables four times faster. A short, ten-minute charge delivers over four hours of play time compared with traditional solutions that can deliver just one-and-a-half hours of play time post charge.
- Smallest Size: The MAX77659 is offered in a tiny 30-bump wafer level package (WLP) that measures 2.55 mm x 2.37mm. Use of a single inductor and integration of the charger reduces the bill of materials by 60 percent for a total solution size of just 22mm2, small enough for the most compact wearable and hearable applications.
